Tecnoglass products
Made big. Made clear.
Insulating, laminated and monolithic glass, curved TecnoBend and high-clarity UltraVIEW, with coatings, frit, silkscreen, digital print and spandrel options.
Insulating glass
Insulating units built from Tecnoglass components: Low-E coatings, glass options, heat treatment and spacers. Pair any R-Series or N-Series coating with clear, low-iron or tinted substrates.
Browse coating performance →Laminated glass
Glass bonded with interlayers, available with R-Series coatings, N70/38 and Solarban 70XL. Specify for safety, security, sound control and impact-rated assemblies.
Interlayer types and makeups: [confirm with Tecnoglass for each project].
Monolithic glass & sizes
Heat-strengthened and fully tempered.
| Thickness | Max, clear or tinted | Max, Low-E |
|---|---|---|
| 1/8″ | 47.24″ × 98.42″ | 47.24″ × 98.42″ |
| 5/32″ | 66.92″ × 98.42″ | 59.05″ × 98.42″ |
| 3/16″ | 78.74″ × 98.42″ | 66.92″ × 98.42″ |
| 1/4″ and over | 130″ × 236″ | 130″ × 236″ |
Minimum: 7.87″ × 11.81″ at 1/8″; 3.93″ × 11.81″ at 5/32″ and over. Source: Tecnoglass monolithic glass sizes.
TecnoBend curved glass
Curved glass for curtain walls, skylights, stairs, elevators, stadiums and bridges, including tempered Low-E. Coated glass keeps its patterns and effects when bent.
- Max size, 3/16″
- 86.61″ × 141.73″
- Max size, 1/4″–5/8″
- 94.48″ × 165.35″
- Min radius, 3/16″–3/8″
- 98.42″–118.11″
- Min radius, 1/2″–5/8″
- 157.48″–236.22″
Radius depends on shape and size. Values per ANSI Z97.1 from Tecnoglass TecnoBend data.
UltraVIEW high-clarity glass
Tempered on ceramic air cushions instead of rollers, so the glass never touches a roller. The result is very low anisotropy (fewer iridescent stripes), better flatness and clearer views.
- 1/8″ heat-strengthened
- 53″ × 98″
- 5/32″–3/16″ tempered
- 66″ × 137″
- 1/4″–3/8″ tempered
- 66″ × 196″
- Minimum size
- 7″ × 19″
